The PP4-X is designed for use with 4-Ohm Punch Pro midrange drivers and tweeters.Read More
The PP4-X is designed for use with 4-Ohm Punch Pro midrange drivers and tweeters. It features dual woofer outputs for use with two Punch Pro midrange drivers. Provides 6dB/Octave dedicated low pass filter for the woofer.
Must use existing built-in 6dB/Octave Punch Pro crossover supplied with tweeter. Designed ONLY for Rockford Fosgate Punch Pro speakers (not designed to be used as a stand-alone passive crossover for other "pro" brands). Mounting hardware included.
Designed for use with Punch Pro midrange drivers and tweeters
125 Watts RMS (250 Watts MAX) power handling
Must use 4-Ohm load on woofer outputs
Dual woofer outputs for use with two Punch Pro midrange
Provides 6dB/Octave, 3kHz low pass for woofer
Works with built-in 6dB/Octave Punch Pro tweeter crossover
Selectable tweeter impedance: 4-Ohm or 8-Ohm
Selectable tweeter attenuation: 0dB, -3dB, -6dB
Mounting hardware included
Sold as individual units (not in pairs)
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
General Specs | |
| Crossover Type | Passive |
| RMS Power Handling (Watts) | 125 |
| Peak Power Rating (Watts) | 250 |
| Number Of Inputs | 1 |
| Number Of Outputs | 3 |
| App Integration | No |
| Color | Black |
| Weight Kilogram | .55 |
| Collection | Punch Pro |
General | |
| Crossover | 4kHz @ 6dB/Octave Low-Pass; 0dB/-3dB/-6dB Tweeter Attenuation |
